Planer. Simple blade setting system for easy/fast blade changes. Can use double edged tungsten blades (supplied) or High Speed Steel blades.

Standard Equipment: Socket wrench, TCT reversible mini blades, blade holding plates

Specification:

Planing Width: 82mm, Planing Depth: 1mm, Max Rebate Depth: 9mm,

Cuts per Minute: 32,000cpm, No Load Speed: 16,000rpm, Input wattage: 550w

Double insulated

110V or 240V

82mm Heavy Duty Planer. Lock-off switch accessible from both sides. Ergonomic rubberised soft grip. Dual side chip ejection. Depth adjustment with click stops.

Standard Equipment: Blade Gauge, Socket Wrench, Guide Rule, Dust Bag

Specification:

Planing Width: 82mm, Planing Depth: 4mm, No Load Speed: 16,000rpm, Input wattage: 850w

Carry case included

Double insulated

110V or 240V

82mm Heavy Duty Planer with constant speed control. Lock-off switch accessible from both sides. Ergonomic rubberised soft grip. Dual side chip ejection. Depth adjustment with click stops.

Standard Equipment: Blade Gauge, Socket Wrench, Guide Rule, Dust Bag

Specification:

Planing Width: 82mm, Planing Depth: 4mm

Carry case included

Double insulated

Electronic speed control

110V or 240V

Planer for Smoothing. Planes up to 110mm (4-3/8") wide and 2mm (1/16") deep in a single pass. Powerful 840W motor in compact and lightweight body (4.2kg / 9.3lbs).

Standard Equipment: Sharpening holder assembly, socket wrench, cutter leveller, HSS planer blades 110mm (x2), planing fence (guide rule)

Specification:

Planing Width: 110mm, Planing Depth: 2mm, Cuts per Minute: 32,000cpm,

No Load Speed: 16,000rpm, Input wattage: 840w

Double insulated

110V or 240V

Heavy Duty Planer. Long rear shoe for stability and control. Max Planing depth: 3mm per pass.

Standard Equipment: Blade gauge assembly, socket wrench, rebate fence (guide rule), carbide mini blades, set plates for mini blades

Specification:

Planing Width: 82mm, Planing Depth: 3mm, Max Rebate Depth: 20mm,

Cuts per Minute: 32,000cpm, No Load Speed: 16,000rpm, Input wattage: 750w

Double insulated

110V or 240V

Planer. Planes a width of 170mm (6-3/4") in a single pass. Max planing depth: 2mm per pass. Unrivalled for sheer power, size and performance.

Standard Equipment: Blade gauge assembly, socket wrench, Rebate fence (guide rule)

Specification:

Planing Width: 170mm, Planing Depth: 2mm, Cuts per Minute: 30,000cpm, No Load Speed: 16,000rpm,

Input wattage: 1,200w

Carry case included

Double insulated

110V

This light and handy electric planer with integrated dust collection bag ensures a clean working environment. The reversible planning blades and the continuously adjustable planning depth is ideal for quick and neat planning. With help of the parallel guide rebate work can be carried out to a depth of 15mm.

Adjustable chipping depth. Dust collection bag. Adjustable folding depth. V groove for easy bevelling. Parallel guide. Large knife wave for optimal working results. Housing surface soft painted.

Technical data:
Mains: 230 V ~ 50 Hz
Power: 900 watts
Idle speed: 16,000 min-1
Planning depth: 0-3 mm
Planning width: 82 mm
Rebate 0-15 mm
Main cable length: 3 m
240V.

Manufacturer code: 44.721.10
